Verl-Tool

VerlTool

VerlTool: A unified and easy-to-extend tool-agent training framework based on verl.

News

[2025/06/18] VerlTool now officially supports Trajectory-Level asynchronous, speeding up the rollout generation with tool calling by at least 2x! see asyncRL.md for more details.
[2024/06/16] We have updated the verl submodule to the latest version (06/16) and modified some code to adapt to the new version.
[2025/06/13] We integrated DeepWiki for Verl-Tool. Feel free to browse the AI-generated docs and chat with Verl-tool codes.
[2025/06/06] We have updated a detailed design overview in the README, including how to add ne 8000 w tools, how to use the tool server, and how to train your own models with verl-tool.
[2025/05/31] We released the Verl-tool training/evaluation code with ToRL training as an initial example (see X post). We are working on the paper and will release it very soon.

Features

🔧 Complete decoupling of actor rollout and environment interaction - We use verl as a submodule to benefit from ongoing verl repository updates. All tool calling is integrated via a unified API, allowing you to easily add new tools by simply adding a Python file and testing independently.
🌍 Tool-as-environment paradigm - Each tool interaction can modify the environment state. We store and reload environment states for each trajectory.
⚡ Native RL framework for tool-calling agents - verl-tool natively supports multi-turn interactive loops between agents and their tool environments.
📊 User-friendly evaluation suite - Launch your trained model with OpenAI API alongside the tool server. Simply send questions and get final outputs with all interactions handled internally. See benchmarks.

Installation

We highly recommend using uv to install verl-tool.

# install uv if not installed first
git submodule update --init --recursive
uv sync
source .venv/bin/activate
uv pip install -e verl
uv pip install -e ".[vllm,acecoder,torl]"
uv pip install "flash-attn<2.8.0" --no-build-isolation

Conda Installation

git submodule update --init --recursive
conda create --name verl-tool-env python=3.10
conda activate verl-tool-env
pip install -e verl
pip install -e ".[vllm,acecoder,torl]"
pip install "flash-attn<2.8.0" --no-build-isolation

Design and Architecture

Design Overview

Verl-Tool is designed to decouple the RL training and the tool calling processes. The RL training components (computation of logp, reward, advantages, RL algorithms, etc.) are handled by the verl framework, while the tool calling process is managed by the tool server through an additional plugin to the verl rollout.

We achieve this by inheriting from ActorRolloutRefWorker → AgentActorRolloutRefWorker in verl_tool/worker/fsdp_workers.py and then overriding the original RefWorker in verl_tool/trainer/main_ppo by adding this line:

from verl_tool.trainer.ppo.ray_trainer import AgentRayPPOTrainer as RayPPOTrainer

We only modify one function after inheriting the ActorRolloutRefWorker class: the generate_sequences function. We add a conditional statement to delegate the agent rollout process to AgentActorManager.run_llm_loop in verl_tool/llm_agent/manager.py:

class AgentActorRolloutRefWorker(Worker, ActorRolloutRefWorker, metaclass=AgentActorRolloutRefWorkerMeta):
    def __agent_init__(self, config: DictConfig, role: str):
        # agent init
        ...
        self.manager = AgentActorManager(...)
        ...

    @register(dispatch_mode=Dispatch.DP_COMPUTE_PROTO)
    def generate_sequences(self, prompts: DataProto):
        ...
            if not self.agent_config.enable_agent:
                # old behavior
                output = self.rollout.generate_sequences(prompts=prompts)
            else:
                # agent behavior (delegated to AgentActorManager)
                output = self.manager.run_llm_loop(prompts) # our agent behavior
        ...

The AgentActorManager handles the multi-turn interaction between the model and the tool server, where the model can call tools and receive observations from the tool server. Please check the detailed design in verl_tool/llm_agent/manager.py.

Configuration parameters are defined in the AgentActorConfig class in verl_tool/llm_agent/config.py. You can set these parameters by adding +actor_rollout_ref.agent.{param_name}=value to the training command.

AgentActorConfig Parameters

Parameter	Type	Default Value	Description
`enable_agent`	bool	`True`	Whether to enable the agent. If False, behaves the same as original verl
`max_turns`	int	`0`	Maximum number of interaction turns
`max_start_length`	int	`None`	Maximum token length of the initial prompt (before any turns)
`max_prompt_length`	int	`None`	Maximum total token length of the prompt (including turns)
`max_response_length`	int	`None`	Maximum token length of the response (e.g., LLM response + observation)
`max_obs_length`	int	`None`	Maximum token length of the observation from environment for each interaction turn
`max_action_length`	int	`None`	Maximum token length of the action (e.g., LLM response) for each interaction turn
`tool_server_url`	str	`None`	URL of the verl-tool server to call tools or APIs
`n`	int	`1`	Number of response samples
`truncate_obs_side`	str	`'left'`	Truncation direction for observations if they exceed length limit ('left' or 'right')
`truncate_response_side`	str	`'left'`	Truncation direction for responses if they exceed length limit ('left' or 'right')
`rolling_with_prompt`	bool	`False`	If True, keeps the system prompt when truncation occurs
`call_tool_first`	bool	`False`	Whether to call tool before generating the response
`min_turns`	int	`0`	Minimum number of actions required before allowing the agent to finish
`action_stop_tokens`	list	`None`	List of stop tokens that indicate the end of an action
`additional_eos_token_ids`	list	`None`	List of additional tokens treated as end-of-sequence
`mask_observations`	bool	`True`	Whether to mask observations in the attention mask and train on them
`force_finish_for_last_turn`	bool	`False`	Force the agent to end after the last turn without tool interaction
`enable_mtrl`	bool	`False`	Whether to enable multi-turn chat format, meaning the observation will be given in a new chat turn for reinforcement learning. If enabled, uses the same format as VLLM Chat Scheduler
`mtrl_role`	str	`user`	If `enable_mtrl` is enabled, this determines the role of the observation chat turn
`mtrl_sep`	str	`None`	In mtrl mode, this defines a special token that if present in the model's action, indicates it wants to interact with the tool server
`turn_end_token`	str	`"<\|im_end\|>"`	Token used to mark the end of each turn

Configuration Examples

1. ToRL-style Training

Critical parameters configuration:

enable_agent=True
max_turns=1 # 1 time of code execution
min_turns=0 # no minimum turns required
action_stop_tokens='```output' # if the model outputs this token, we consider it wants to interact with the tool server
enable_mtrl=False # no multi-turn chat format

Trajectory format:

To solve this problem...
```python
...
```
```output
...
```
So the answer is ...

When does a trajectory stop? Since min_turns=0, the model will finish the trajectory either by generating an EOS token without any action stop tokens or by reaching max_turns=1.

2. Multi-turn RL Training

Trajectory format:

To solve the problem ...
```python
...
```
...
<|im_end|>
<|im_start|>user
```output
...
```
<|im_end|>
<|im_start|>assistant
So the answer is ...

Critical parameters configuration:

enable_agent=True
max_turns=3 # 3 turns
min_turns=3 # force the model to call tools at least 3 times
action_stop_tokens='' # since always forcing, the action tokens are not needed
enable_mtrl=True # multi-turn chat format
mtrl_role=user # the observation will be given in a new chat turn
# add --done_if_invalid True to the verl-tool server command to ensure the trajectory stops when no tool matches

When does a trajectory stop? Since min_turns=3 and max_turns=3, the model always tries to call tools by sending each turn's response. This response goes through each active tool to check for valid matches determined by the parse_action method. If any tool matches, the trajectory continues. If no tool matches, the trajectory stops and returns the final response.

Tool Server Design

Verl-Tool provides a unified tool server interface that allows you to easily add new tools and manage the tool calling process. The tool server is designed to handle multiple tools and can be extended to support new tools by simply adding a new Python file in the verl_tool/servers/tools directory.

The overall execution pipeline of a tool server is as follows:

Request Reception: The tool server receives a request from the model in the following format:

{
    "trajectory_ids": ["traj_id_1", "traj_id_2", ...],
    "actions": ["action_1", "action_2", ..."],
    "finish": [false, true, ...], // whether a trajectory is finished and should not perform action
    "is_last_step": [false, false, ...], // whether this is the last step of the trajectory
    ... // other parameters
}

Action Processing: For each action in the request, the tool server tries to parse the action using all active tools (in the identify_tool_for_action method). If any tool's parse_action returns a valid sign, the action is sent to that tool's get_observations (or conduct_action) method to get the observation. If no tool matches, the observation will be an empty string, the valid sign will be False, and whether the trajectory is finished is determined by the done_if_invalid parameter when starting the tool server.
Finish Handling: The special finish field indicates whether the trajectory is determined to be finished on the verl side, meaning the model doesn't want to call any tool and the trajectory is finished. If this is set to True, the tool server directly sends the action to the special finish tool to clean up the corresponding trajectory's environment state.
Response: The tool server returns observations in the following format:

{
    "observations": ["observation_1", "observation_2", ...],
    "dones": [false, true, ...], // whether the trajectory is finished
    "valids": [true, false, ...] // whether the action is valid (i.e., whether the action was parsed by any tool)
}

Tool Server Usage

We provide a tool server starting command to start any tool server supported by verl-tool (see the full list in verl_tool/servers/tools). To start the tool server, use the following command:

# Start the tool server
host=localhost
port=5500
tool_type=python_code # separate by comma if you want to start multiple tool servers
workers_per_tool=4 # number of workers for the tool server, meaning how many threads will be used to handle a single tool request with multiple trajectories
python -m verl_tool.servers.serve --host $host --port $port --tool_type $tool_type --workers_per_tool $workers_per_tool & # run in background

After running, you should see the following output. Tools marked with 🟢 are active, while those marked with ⚪ are inactive. The finish tool is always added to manage the end of each trajectory (e.g., delete environment state):

2025-06-05 14:28:24,029 - __main__ - INFO - Initializing tools: ('python_code',)
2025-06-05 14:28:24,037 - __main__ - INFO - Initialized tool: python_code
2025-06-05 14:28:24,037 - __main__ - INFO - Available Tools:
2025-06-05 14:28:24,037 - __main__ - INFO -   - base: inactive ⚪
2025-06-05 14:28:24,037 - __main__ - INFO -   - text_browser: inactive ⚪
2025-06-05 14:28:24,037 - __main__ - INFO -   - finish: active 🟢
2025-06-05 14:28:24,037 - __main__ - INFO -   - piston: inactive ⚪
2025-06-05 14:28:24,037 - __main__ - INFO -   - ipython_code: inactive ⚪
2025-06-05 14:28:24,037 - __main__ - INFO -   - python_code: active 🟢
2025-06-05 14:28:24,037 - __main__ - INFO -   - sandbox_fusion: inactive ⚪
2025-06-05 14:28:24,037 - __main__ - INFO -   - python_oj: inactive ⚪
2025-06-05 14:28:24,038 - __main__ - INFO - Starting async server on localhost:5500
2025-06-05 14:28:24,038 - __main__ - INFO - Server configured for up to 128 concurrent requests
INFO:     Started server process [2897325]
INFO:     Waiting for application startup.
INFO:     Application startup complete.
INFO:     Uvicorn running on http://localhost:5500 (Press CTRL+C to quit)

To test the tool server, we provide corresponding test scripts in the verl_tool/servers/tests directory. For example, to test the python_code tool server:

# Test the python_code tool server
python -m verl_tool.servers.tests.test_python_code_tool python --url=http://localhost:$port/get_observation
# python -m verl_tool.servers.tests.test_bash_terminal_tool bash --url=http://localhost:$port/get_observation

Training

Data Preprocessing

Prepare the data for training using the provided scripts. More examples can be found in examples/data_preprocess.

python examples/data_preprocess/deepmath.py --data_source zwhe99/DeepMath-103K --local_dir data/deepmath_torl --sys_prompt_style torl
# use simple_rl style for non-tool system prompt

Single Node Training

We provide an integrated training script for each example. To train ToRL, run the following command:

bash examples/train/torl/train_qwen_1.5B_math_deep_math.sh

See more examples in examples/train, where each folder is a separate project with its own training script. You can also submit a PR to add your own training script to the project.

Training Tips:

For low VRAM GPUs: Set do_offload=True, enforce_eager=True, tensor_parallel_size=1, use_dynamic_bsz=False, and use a small ppo_micro_batch_size_per_gpu.
For high VRAM GPUs: Set do_offload=False and use_dynamic_bsz=True to speed up training.
If VLLM generation gets stuck: Try lowering workers_per_tool and reducing gpu_memory_utilization in the script.
If you encounter CPU OOM issues during VLLM rollout generation: Try setting do_offload=False and lowering gpu_memory_utilization.
See verl performance tuning for more details.

Multi Node Training (Experimental)

Head Node

ray start --head --dashboard-host=0.0.0.0 # start ray head node
bash examples/train/acecoder/train.sh # train the model

Worker Node

ray start --address='head_node_ip:6379' --block # start ray worker node
# no need to run the training script on worker node

Training Logs

During training, the generated responses, rewards, etc., of each step are recorded in the verl_step_records directory. The corresponding code logic is written in the verl_tool/worker/reward_manager/{reward_manager_name}.py file. This helps you debug the training process and understand how the model interacts with the tool server.

Evaluation

Evaluating verl-tool trained models is naturally challenging due to the tool calling nature, where we need to maintain not only the model's inference engine (e.g., VLLM or SGLang) but also the tool server that allows the models to interact. Therefore, to better facilitate the evaluation service, we wrap the entire interaction process into an OpenAI-like API service, where you can simply send messages in the OpenAI chat format and the rest of the multi-turn interaction between the inference engine and the tool server will be handled internally by the service, returning the final result in the OpenAI response format.

Specifically, the service can be accessed via OpenAI's client.chat.completions.create or client.completions.create API. When accessing, please ensure the model name corresponds to the one being set in the script. The server is managed by app.py, while the main tool-calling logic is implemented in model_service.py. config.py's default parameters are overridden in scripts/start_api_service.sh.

Evaluation Service Setup

We use our published checkpoint 🤗VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step as an evaluation example.

Content of eval_service/scripts/start_api_service.sh:

#!/bin/bash
set -x
# 1. Start Tool Server
host=0.0.0.0
port=$(shuf -i 30000-31000 -n 1)
tool_server_url=http://$host:$port/get_observation
python -m verl_tool.servers.serve --host $host --port $port --tool_type "python_code" --workers_per_tool 32 --done_if_invalid True --silent True &
server_pid=$!
echo "Server (pid=$server_pid) started at $tool_server_url"

# 2. Start API service
model_path=VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step
max_turns=4 # defines the maximum number of interaction turns between the model and the tool server, if set to 0, it will not limit the number of turns
min_turns=0 # defines the minimum number of action turns between the model and the tool server, will force the model to call tools at least this many times, if set to 0, it will not force the model to call tools
api_host="0.0.0.0"
api_port=5000
action_stop_tokens='```output' # stop at this token, then send the output to the tool server, this is a special token that we use to indicate the end of the action, you can change it to any other token that your model will produce when it is asking for a tool calling round
tensor_parallel_size=1
num_models=1 # number of vllm instances; num_models * tensor_parallel_size should be equal to the number of GPUs
enable_mtrl=False # whether to evaluate in multi-chat-turn setting (taking each observation as a new chat turn)
# temp file for action tokens as verl cannot pass special strings as params
action_stop_tokens_file=$(mktemp)
echo "$action_stop_tokens" > $action_stop_tokens_file
echo "action_stop_tokens_file=$action_stop_tokens_file"

python eval_service/app.py \
    --host $api_host \
    --port $api_port \
    --tool-server-url $tool_server_url \
    --model $model_path \
    --max_turns $max_turns \
    --min_turns $min_turns \
    --action_stop_tokens $action_stop_tokens_file \
    --tensor-parallel-size $tensor_parallel_size \
    --num-models $num_models \
    --enable_mtrl $enable_mtrl

api_server_pid=$!
echo "API started at $api_host:$api_port"

# 3. Kill all servers
pkill -9 -P $server_pid
kill -9 $server_pid
pkill -9 -P $api_server_pid
kill -9 $api_server_pid

Steps:

Start the Python code execution tool server and API Service: eval_service/scripts/start_api_service.sh

bash eval_service/scripts/start_api_service.sh &

This starts both the tool server and the API service, where the tool server handles tool calling requests from the model, and the API service handles OpenAI-like API requests. When you see the following output, the API service is running successfully:

INFO:     Started server process [671818]
INFO:     Waiting for application startup.
INFO:     Application startup complete.
vLLM instance model-0 status: SyncPage[Model](data=[Model(id='VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step', created=1749194165, object='model', owned_by='vllm', root='VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step', parent=None, max_model_len=4096, permission=[{'id': 'modelperm-459bedc083f4492b8d908b521c2447c7', 'object': 'model_permission', 'created': 1749194165, 'allow_create_engine': False, 'allow_sampling': True, 'allow_logprobs': True, 'allow_search_indices': False, 'allow_view': True, 'allow_fine_tuning': False, 'organization': '*', 'group': None, 'is_blocking': False}])], object='list')
✅ vLLM service started successfully with model: VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step

Testing the API Service

We provide test scripts in eval_service/test/test_api.py to test the API service. You can run the following command:

model_name=VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step
test_task=math # or code
test_type=chat_completion # or completion
base_url=http://localhost:5000 # replace with your local server address
python eval_service/test/test_api.py --model_name $model_name --test_task $test_task --test_type $test_type --base_url $base_url

Example output:

Testing math task...
Testing math with chat_completion on model VerlTool/torl-deep_math-fsdp_agent-qwen2.5-math-1.5b-grpo-n16-b128-t1.0-lr1e-6-320-step at http://localhost:5000
To convert the point $(0,3)$ from rectangular coordinates to polar coordinates, we need to find the radius $r$ and the angle $\theta$.

The radius $r$ is the distance from the origin to the point and can be calculated using the formula:
\[ r = \sqrt{x^2 + y^2} \]
where $x$ and $y$ are the rectangular coordinates. For the point $(0,3)$, we have $x = 0$ and $y = 3$.

The angle $\theta$ is the angle formed with the positive x-axis and can be calculated using the formula:
\[ \theta = \arctan\left(\frac{y}{x}\right) \]
However, since $x = 0$, we need to consider the special case where the point lies on the y-axis. In this case, $\theta = \frac{\pi}{2}$ if $y > 0$ and $\theta = \frac{3\pi}{2}$ if $y < 0$. Since $y = 3 > 0$, we have $\theta = \frac{\pi}{2}$.

Let's calculate this using Python to ensure accuracy.
```python
import math

# Rectangular coordinates
x = 0
y = 3

# Calculate the radius r
r = math.sqrt(x**2 + y**2)

# Calculate the angle theta
# Since x = 0, we need to handle the special case
if x == 0:
    if y > 0:
        theta = math.pi / 2
    elif y < 0:
        theta = 3 * math.pi / 2
    else:
        theta = 0  # or 2*pi, but we'll use 0 for simplicity
else:
    theta = math.atan2(y, x)

print(((r, theta)))
```
```output
(3.0, 1.5707963267948966)
```
The polar coordinates for the point $(0,3)$ are $(3.0, \frac{\pi}{2})$. Therefore, the final answer is:

\[
\boxed{(3, \frac{\pi}{2})}
\]

Math Benchmark Results

1.5B Model Performance across challenging mathematical benchmarks:

Model Name	Tool	GSM8K	MATH 500	Minerva Math	Olympiad Bench	AIME24	AMC23	Avg
Qwen2.5-Math-1.5B	❌	39.50	34.80	8.10	23.00	13.30	35.00	25.62
Qwen2.5-Math-1.5B-Instruct	❌	84.90	74.20	26.80	39.00	10.00	57.50	48.70
Qwen2.5-Math-1.5B-Instruct + SimpleRL-Zoo	❌	81.90	70.20	20.60	33.90	20.00	55.00	46.90
Qwen-2.5-Math-1.5B-Instruct-TIR	✅	83.70	76.20	24.30	41.30	26.70	55.00	51.20
ToRL-1.5B	✅	85.60	77.80	29.80	44.00	26.70	67.50	55.23
Qwen-2.5-Math-1.5B + Verl-Tool	✅	85.10	77.40	28.30	44.00	33.30	65.00	55.52

7B Model Performance across challenging mathematical benchmarks:

Model Name	Tool	GSM8K	MATH 500	Minerva Math	Olympiad Bench	AIME24	AMC23	Avg
Qwen-2.5-Math-7B	❌	65.50	63.60	12.50	25.80	13.30	42.50	37.20
Qwen2.5-Math-7B-Instruct	❌	95.20	83.00	37.10	41.60	16.70	70.00	57.27
Qwen-2.5-Math-7B + SimpleRL-Zoo	❌	88.80	80.20	26.80	41.60	30.00	52.50	53.30
Qwen-2.5-Math-7B-Instruct-TIR	✅	94.60	82.40	29.00	50.50	30.00	62.50	58.17
TORL-7B	✅	92.70	82.20	33.50	49.90	43.30	65.00	61.10
Qwen-2.5-Math-7B + Verl-Tool	✅	91.40	83.40	29.80	50.20	40.00	72.50	61.22

Model Checkpoints

All these models are available in our Huggingface Collection.

Model	Link	Wandb
Qwen-2.5-Math-1.5B-Verl-tool	🤗	📈
Qwen-2.5-Math-7B-Verl-tool	🤗	📈

Updating verl version

To update the verl submodule to the latest version, run the following commands in the verl-tool root directory:

cd verl && git pull origin main && cd ..
cp -r verl/verl/trainer/config/* ./verl_tool/trainer/config/
uv pip install -e verl

Note there might be some small parameters needed to remove the '+' prefix in the training script because default values may be added to the new config files.

Contributing

Adding New Tools

Go to the ./verl_tool/servers/tools directory. Each tool has a name (e.g., base, python_code). The tool name is exactly the name of the Python file you should create in the directory. See ./verl_tool/servers/tools/python_code.py for an example.

Creating New Reward Managers

Go to the ./verl_tool/worker/reward_manager directory and add your new reward manager. Then, make sure to update the verl_tool/trainer/main_ppo.py file to include your new reward manager.

ToDos

Async rollout and tool interaction for each trajectory using VLLM and SGLang
Integrate MCP server interface as a general tool type
Pixel Reasoner integration

Core Contributors

Advisors

_{Wenhu Chen}

_{Tianyu Pang}

_{Chao Du}

Acknowledgements

We thank the following open-source projects for making verl-tool possible:

VLLM and SGLang for their fast LLM inference support!
verl for the excellent RL framework design.
SearchR1, RAGEN, and ToRL for their early-stage exploration of tool-agent RL training.

We thank Netmind.AI, SeaAI Lab, and Map for GPU support!

Name		Name	Last commit message	Last commit date
Latest commit History 406 Commits
assets		assets
benchmarks		benchmarks
eval_service		eval_service
examples		examples
verl @ 38d9a88		verl @ 38d9a88
verl_tool		verl_tool
.gitignore		.gitignore
.gitmodules		.gitmodules
.python-version		.python-version
LICENSE		LICENSE
README.md		README.md
main.py		main.py
pyproject.toml		pyproject.toml
requirements.txt		requirements.txt

License

TIGER-AI-Lab/verl-tool

Folders and files

Latest commit

History

Repository files navigation

Verl-Tool

VerlTool: A unified and easy-to-extend tool-agent training framework based on verl.

Table of Contents

News

Features

Installation

Conda Installation

Design and Architecture

Design Overview

AgentActorConfig Parameters

Configuration Examples

1. ToRL-style Training

2. Multi-turn RL Training

Tool Server Design

Tool Server Usage

Training

Data Preprocessing

Single Node Training

Multi Node Training (Experimental)

Training Logs

Evaluation

Evaluation Service Setup

Testing the API Service

Math Benchmark Results

Model Checkpoints

Updating verl version

Contributing

Adding New Tools

Creating New Reward Managers

ToDos

Core Contributors

Advisors

Acknowledgements

Star History

About

Topics

Resources

License

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Contributors 11

Uh oh!

Languages

Packages
